MO-2014 High Precision Micro-Ohm up to Meter 10A

Features:

• 4 terminal devices for accurate measurement of very low resistance.
• Ideal for measuring the resistance of components precisely.
• Ideal for testing protective conductors, lightning conductors and welded points.
• Maximum test current is 10A (60000 micro Ohm range only)
• Have two working mode, Resistive and Inductive mode, Normal is resistive mode.
• Good/Fail set-function for input quality control.
• Built-in buzzer sound (GOOD STATUS) to assist the Q.C. judgment.
• Especial CALCULATE function to measure cable/wire length.
• Wide measuring range, 1 micro ohm - 6 Kilo ohm, 6 ranges.
• Large size and back-light LCM display, easy read-out.
• LSI circuit provides high accuracy, reliability and durability.
• Built-in over input protection.
• Durable bench type housing plastic case stand.

Product Specifications

GENERAL

Battery Type:

DC 1.5V Battery AA 8 Nos

Brand:

Lutron

Dimensions:

225x125x64 mm

Measuring Range:

60000 micro Ohm to 6000 Ohm

Model:

MO 2014

Operating temperature:

50 degree celsius

Weight:

790 grams
